Overview

 Print Brochure

INTENSE


Distinguished by its incredible high-speed handling and stand-up riding capabilities, the FZS sends a ripple through the industry that will be felt for years to come. Its aerodynamic hull design combines remarkable tight turning with an edge-to-edge inside lean character for unparalleled precision. Incorporating an extended seat into its aggressive design, the FZS also offers passengers the opportunity to experience the refined ferocity of a Yamaha musclecraft.

    The Powerplant
    • The FZS is powered by a 1.8 liter, supercharged, super high output Yamaha Marine Engine. This 1812cc engine, which is purpose-built for the marine environment, is the largest displacement engine ever installed in a personal watercraft. It is also the only engine in the high-performance, four-stroke category optimized to run on the least expensive Regular Unleaded fuel.
    • Electronic Fuel Injection (EFI): Four electronically controlled fuel injectors, throttle position sensor (TPS) and intake air pressure and air temperature sensors supply the optimum air/fuel mixture. The results are a smooth, high power output with low fuel consumption and low exhaust emissions.
    • Specially Designed, One-piece Cylinder and Crankcase Assembly: Provides tremendous engine rigidity that's lighter and stiffer than two-piece designs.
    • Slant Detection Switch: Electronic switch stops engine and oil pumps immediately if watercraft becomes overturned, protecting motor from unwanted water ingestion.
    • High Volume Intake Box: With water repellent air filter and flame arrestors.
    • Wet Sump Lubrication: Uses two engine oil pumps to deliver lubricated oil to each moving part with water-jacketed sump and oil backflow protection.
    • Independent Water-jacketed Exhaust Manifolds with Collector: Achieves high power while keeping noise and exhaust heat under control.
    • Thermostatic Cooling System: Water flow through the engine is automatically controlled through a thermostat sensor.
    • Corrosion Protection System: Sacrificial zinc anodes protect the engine from harmful galvanic corrosion. Stainless steel fasteners (nuts, bolts, hardware) provide a long service life. Cylinders, cases and heads are all treated with a durable oxide coating to form a barrier between corrosion and expensive engine parts.
    • Electronically Controlled, Variable Ignition Timing: For exact ignition advance control at all throttle positions and RPMs.
    • Direct Ignition: For more efficient combustion.
    The Jet Pump Propulsion System
    • The FZS 155mm hyper-flow jet pump propulsion system with three-blade stainless steel impeller is designed to maximize water flow for high performance. The FZR pump configuration provides excellent hook-up and smooth acceleration.
    • The industry’s only Reverse with Traction Control technology: maintains the perfect RPM to provide the optimal speed for effectively maneuvering when the watercraft is in reverse.
    • Quick Shift Trim System (Q.S.T.S.): Mechanically operated, this system offers instant change in the attitude of the watercraft while underway allowing for tighter turns or quicker acceleration on plane, as the rider prefers. Q.S.T.S. offers 24 degrees of total trim range.
    • Stainless Steel Impeller Housing Liner: For high durability, the liner maintains accurate clearance tolerances between the impeller and the housing.
    • High Flow Intake Duct and Grate: The dynamic shape of these items directs water flow into the pump for better thrust, performance and hook up.
    • Pumps are Manufactured with YDC30: A combination of zinc and copper alloys, developed by Yamaha marine engineers, that offers excellent corrosion protection.
    The NanoXcel Hull and Deck
    • The FZS features the world’s first hulls and decks manufactured through the use of cutting edge nanotechnology. Yamaha’s new NanoXcel ultra-lightweight, high strength material reduces the weight of the hull, deck and liner by 25% and provides performance gains in acceleration, top speed and performance-driven handling. Additionally, the NanoXcel material offers a shinier, gem-like finish which reduces surface tension on the water, providing a more nimble, responsive ride.
    • All New Performance-Enhanced Hull: provide excellent agility and maneuverability.
    • Sponson Design: Provides added straight-line comfort and an improved two and three-up riding experience.
    Additional Features
    • Telescopic Steering: Three variable positions designed to give the driver the option of standup riding, traditional sit-down riding or low to get even closer to the action.
    • Dual Analog Meters: Provides the operator a quick read on speed, RPM, fuel level, low fuel warning, low oil pressure warning, battery voltage, overheat warning, hour meter, check engine light with self-diagnostic function and the industry's only audible warning system.
    • Industry's First Remote Controlled Transmitter: With the touch of a button on Yamaha’s innovative remote controlled transmitter, you can activate and deactivate the FZS's digital security system and all-new Low RPM Mode from up to 30 feet away.
    • Low RPM Mode™: The personal watercraft industry’s first fuel saving feature, Low RPM can reduce fuel consumption by up to 26% based on average annual use.
    • Yamaha Security System: This security system that can be activated with the touch of a button ensures that no one starts the FX SHO without your permission.
    • 21.3 Gallons of Total Storage: Includes a large, watertight storage compartment under the seat and the glove box.
    • Glove Box with Self-draining Beverage Holders: The industry's first self-draining beverage holders.
    • Dual Mirrors: Automotive style and convenience.
    • Finger Throttle Lever: Provides added comfort while reducing hand fatigue.
    • Yamaha's Trademarked Visibility Spout®: A waterspout from the rear of the craft that improves the watercraft’s conspicuity.
    Specifications
    • Engine Type: 4-Cylinder, 4-Stroke
    • Bore/Stroke: 86 x 78mm
    • Displacement: 1812cc
    • Fuel: Regular Unleaded
    • Type of Exhaust: Wet
    • Type of Lubrication: Wet Sump
    • Cooling: Open-Looped, Water
    • Starting: Electric
    • Ignition: Direct Ignition
    • Compression Ratio: 8.6:1
    • Carburetor/Injection: Electronic Fuel Injection
    • Ignition Timing: 20° BTDC
    • Spark Plug: NGK LFR6A
    • Pump: 155mm Axial Flow
    • Transmission: Direct Drive from Engine
    • Impeller: 3-Blade, Stainless Steel
    • Length: 132.7” (3.37m)
    • Width: 48.4” (1.23m)
    • Height: 45.7” (1.16m)
    • Dry Weight: 813lb (369kg)
    • Fuel Capacity: 18.5 gal (70 L)
    • Oil Capacity: 1.1 gal (4.2 L)
    • Vehicle Capacity: 3 person/ 529 lbs (240 kg)
    • Storage Capacity: 21.3 gal (80.6 L)
    • Hull Material: NanoXcel
    • Warranty: 1 year limited warranty
    • Color: Crimson Red Metallic; Stealth Black
    NOTES:

    Price and specifications subject to change without notice. Please read your Owner's Manual and all labels before operation.


    Specifications

    Engine
    Engine Type 4-Cylinder, 4-Stroke
    Displacement 1812 cc
    Bore and Stroke 86 x 78 mm
    Cooling Open-Looped, Water
    Compression Ratio 8.6:1
    Fuel System Electronic Fuel Injection
    Ignition Direct Ignition; Ignition Timing: 20° BTDC
    Starting Electric
    Dimensions
    Dry Weight 813 lbs (369 kg)
    Fuel Capacity 18.5 gal (70 l)
    Height 45.7 in. (1.16 m)
    Length 132.7 in. (3.37 m)
    Width 48.4 in. (1.23 m)
    Oil Capacity 1.1 gal (4.2 l)
    Rider Capacity 3 person/ 529 lbs. (240 kg)
    Storage Capacity 21.3 gal (80.6 l)
    Drive Unit
    Impeller 3-Blade, Stainless Steel
    Pump 155 mm Axial Flow
    Transmission Direct Drive from Engine
    General
    Speedometer Analog
    Tachometer Analog
    Mirrors Dual Mirrors
    Hull Type NanoXcel
    Color Crimson Red Metallic, Stealth Black
    Warranty 1 year limited warranty

    Compare Models

    		 Print








    Year 2009
    Manufacturer Yamaha
    Model FZS
    Style Performance
    MSRP* $17,417.00
    Dimensions
    Dry Weight 813 lbs (369 kg)
    Fuel Capacity 18.5 gal (70 l)
    Height 45.7 in. (1.16 m)
    Length 132.7 in. (3.37 m)
    Width 48.4 in. (1.23 m)
    Oil Capacity 1.1 gal (4.2 l)
    Rider Capacity 3 person/ 529 lbs. (240 kg)
    Storage Capacity 21.3 gal (80.6 l)
    Drive Unit
    Impeller 3-Blade, Stainless Steel
    Gear Ratio
    Pump 155 mm Axial Flow
    Transmission Direct Drive from Engine
    Engine
    Engine Type 4-Cylinder, 4-Stroke
    Displacement 1812 cc
    Bore and Stroke 86 x 78 mm
    Cooling Open-Looped, Water
    Compression Ratio 8.6:1
    Fuel System Electronic Fuel Injection
    Ignition Direct Ignition; Ignition Timing: 20° BTDC
    Starting Electric
    General
    Speedometer Analog
    Tachometer Analog
    Mirrors Dual Mirrors
    Hull Type NanoXcel
    Color Crimson Red Metallic, Stealth Black
    Warranty 1 year limited warranty
